Wheels
Keystone Castors & Wheels stocks the widest range of castor wheels suitable for most castor and industrial applications. We have been Castor & Wheel specialists since 1926. Whether you're looking for a replacement caster wheel or a bulk purchase of industrial wheels we have the knowledge, experience and stock availability to assis...t you in making the best choice.Browse Keystone wheels online for a Industrial wheel suitable for Material Handling Trolleys , Industrial carts, Sack Trucks , Pneumatic Wheel applications, V Groove Rail wheels, Flange Rail wheels, Machine Wheels and Drive Wheels or call one our our experienced Technical Sales team for help you make your selection.
Because we carry vast stock of caster and trolley wheels we can handle large orders and small orders from both domestic and business customers. Our UK Castor & Wheel stocks include many models. Including nylon, rubber tyre, polyurethane, cast iron, polypropylene tyre , pneumatic (inflatable), puncture proof wheels (flat free wheels). All these castor wheels can have various options for bearings: Roller, Ball or Plain Bearings.
About Caster Wheel Bearings
The type of bearing used in a castor wheel affects the running properties of it and therefore the mobility of the unit they are fitted to:
Plain Bore Bearings (Plain Bore)
This is the most economical type of bearing. In fact, there isn't one. The wheel turns around an axle tube. They are great if the equipment they are attached to does not have to move much and when it does without a great deal of weight on it. Under normal circumstances, they are maintenance free and corrosion resistant.
Revvo PT Designer industrial wheels are available with a keyway.
Roller Bearings
This type has a series of steel rollers within a cage. The rollers rotate between the axle tube and the wheel hub. Using these bearings means that the rolling resistance of the bearing is very small, even under heavy load. This type of bearing is the most commonly used especially for transportation equipment. They are robust and generally maintenance free. Please note, in stainless steel castors the rollers are stainless steel and in high temperature wheels, the cage is made from steel.
Ball Bearings
Castor wheel ball bearings consist of a stamped sheet metal housing enclosing an inner and outer ring. The ball bearings run between these two rings. This type of bearing has excellent running properties even under very heavy loads and at high speeds. Because the bearings are sealed, these bearings do not need to be lubricated. This is the engineers choice for apparatus castors and heavy duty casters in most applications. Read More
- Display 15 Products per page
In StockRubber Tyre Trolley/Sack Truck Wheel 180mm | Black Rubber / Red Polypropylene (Plastic) Centre, 200kg, 25.4mm Plain Bore (EPR18025.4/51RED)
£7.04... Read More initial; background-position: initial; background-size: initial; background-repeat: initial; background-attachment: initial; background-origin: initial; background-clip: initial;">180mm Black Solid Rubber Tyre on a Red Polypropylene (Plastic) Centre Sack Truck wheel with 1 inch (25.4mm) Plain Bore. Load Capacity = 175kg.
This 7 inch (18 centimetre) diameter wheel (from outside edge of the black rubber tyre) is suitable for use as a trolley or cart wheel, sack truck wheel, castor wheel or anywhere where the axle the wheel is being fitted onto has a 24.5mm (1 inch) diameter.
- In Stock
Castor Wheel 160mm | Polyurethane Tyre / Aluminium Centre, 600kg, 20mm Ball bearing (AW160PAB)
£32.97160mm Castor Wheel with a Polyurethane Tyre (Shore... Read More A 94) on an Aluminium Centre with 20mm Ball bearings. Load Capacity = 600kg using manual propulsion at 4km/h.Key Specifications:- Tread Width: 50mm
- Hub Length: 60mm (the distance through the central bore)
- Bearing Type: 20mm Ball Bearing
- Tyre Hardness: Shore A 94
- High Load Capacity
- Low Rolling Resistance
- High Wear Resistance
- Low Noise Operation
- In Stock
Castor Wheel 75mm | Polyurethane Tyre / Cast Iron Centre, 300kg, 12mm Ball Bearing (07535PT212)
£68.3975mm Polyurethane (Premium Grade REVVOTHANE) Ty... Read Morere on a Cast Iron Centre Wheel running on precision 12mm Ball Bearings.This is high performance wheel and the stated load capacity is based on the wheel being manually propelled at 4 km/h (walking speed).
As a high performance wheel it is often used in much more demanding applications than a standard polyurethane tyre castor wheel. As with all polyurethane tyred wheels, demanding applications involving extended periods of use or speeds greater 4 km/h the friction will generate heat build up in the polyurethane. REVVOTHANE is a high quality polyurethane that offers minimal heat build up and performs exceptionally well within the following guidelines:
- If the wheel be in continual use for more than 45 minutes, this reduces the load capacity by 25%.
- The load capacity is reduced by a further 30% if used as Drive Wheel
- Reduce load by further 20% if the running speed is between 6 km/h and 10 km/h
- Reduce the load by a further 30% if the running speed is between 10 km/h and 16 km/h
- In Stock
Castor Wheel 63mm | Rubber Tyre / Nylon Centre, 45kg, 9.5mm Plain Bore (WRN25)
£4.1963mm Rubber Tyred / Nylon Centre (Wheel - Resilien... Read Moret Tread) with Plain Bore. Load Capacity = 45kg - In Stock
Puncture Proof Wheel 300mm | Puncture Proof Tyre / Red Polypropylene Centre, 150kg, 25.4mm Roller Bearing (PP300RPB1D)
£52.04300mm Puncture Proof Wheel (Micro-Cellular Polyure... Read Morethane) with a Diamond Tread on a Red Polypropylene Centre. This Wheel has a 25.4mm Roller Bearing, 100mm Tread Width, 73mm Hub Length, and 150kg Load Capacity - In Stock
Castor Wheel 75mm | V Grooved Cast Iron, 225kg, 20mm Roller Bearing (075CV1B)
£33.9975mm Cast Iron Wheel (Wheel - V Grooved) with 20m... Read Morem Roller Bearing. Load Capacity = 225kg - In Stock
Castor Wheel, 150mm | V Grooved Cast Iron, 1000kg Capacity, 20mm Ball Bearing (150CV2H)
£66.95150mm V-Groove Cast Iron Wheel (Genuine Revvo bran... Read Mored) with a clear resin shellac finish and a 20mm Ball Bearing. The wheel's load capacity is 1,000kg and is ideal for use on inverted angle iron rail. - In Stock
100mm White Nylon Wheel, 12mm Roller Bearing, 150kg (MVW100NY1B)
Original price was: £6.90.£3.10Current price is: £3.10.Sale!100mm White Nylon Castor Wheel with 12mm Roller Be... Read Morearing, 36mm Tread Width and 40mm Hub Length (the distance through the central bore). The load Load Capacity is 150kg.The 100mm wheel wheel comes with thread guards, an M12x36mm Needle Roller Bearing, a Steel Tube (12mm OD X 8mm ID x 40mm Length) and a 8mm x 59mm Bolt & nut.Without the castor wheel's tube fittings, the plain bore is 20mm. - In Stock
Puncture Proof Wheel 300mm | Puncture Proof Tyre / Red Steel Centre, 150kg, 25.4mm Plain Bore (PP300RS1D)
£61.08300mm Puncture Proof Wheel (Micro-Cellular Polyure... Read Morethane) on a Red Steel Centre. This Wheel has a 25.4mm Plain Bore, 100mm Tread Width, 68mm Hub Length, and 150kg Load Capacity - In Stock
Castor Wheel 100mm | Polyurethane Tyre / Nylon Centre, 125kg, 8mm Ball bearing (AW100NPB)
£11.93100mm Castor Wheel with an Orange Polyurethane Tyr... Read Moree on a Black Nylon Centre, The wheel has a 30mm Tread Width and 40mm Hub Length with an 8mm Single Ball Bearing and a Load Capacity of 125kg - In Stock
Castor Wheel 125mm | Nylon, 150kg, 8mm Ball bearing (7335090)
£4.35125mm White Nylon Wheel Castor wheel with Grey Thr... Read Moreead Guards and a single ball bearing held in place by two integral thread guards. The load capacity of this caster wheel is 150kg using manual propulsion at 4km/h (walking speed)Key Specifications:- Tread Width: 35mm
- Hub Length: 45mm (Including the Thread Guards)
- Bore Size: 8mm
- Bearing Type: Single Ball Bearing
- Wheel Hardness: Shore D 75
- High Load Capacity
- Wear Resistant
- Low Rolling Resistance
- Extremely resistance to water, salts, greases, acids and alkalis
- In Stock
Castor Wheel 100mm | Polyurethane Tyre / Cast Iron Centre, 340kg, 20mm Ball Bearing (100PT2H)
£62.80100mm Polyurethane Tyre on a Cast Iron Centre C... Read Moreastor Wheel (Revvo) with 57mm Hub Length (the distance through the central bore) and a 20mm Ball Bearing. Load Capacity = 340kg
This polyurethane tyre has a high tear strength, exceptional abrasion resistance and a useful life of up to 10 times that of equivalent rubber tyres under similar conditions and loads.
- In Stock
Puncture Proof Wheel 300mm | Puncture Proof Tyre / Red Steel Centre, 150kg, 25.4mm Roller Bearing (PP300RSB1D)
£63.11300mm Puncture Proof Wheel (Micro-Cellular Polyure... Read Morethane) on a Red Steel Centre. This Wheel has a 25.4mm Roller Bearing, 100mm Tread Width, 65mm Hub Length, and 150kg Load Capacity - In Stock
Puncture Proof Wheelbarrow Wheel 355mm | Black Rubber tyre / Steel Centre, 16mm / 19mm bore
Original price was: £44.13.£30.89Current price is: £30.89.Sale!355mm (14") diameter puncture proof wheelbarrow wh... Read Moreeel with a White Painted Steel centre (3.50-8). This wheel suits either 16mm (5/8") or 19mm (3/4") axles and is sold with spacers to vary the hub wheel's hub length (the distance through the central bore). With a 180kg load capacity it is suitable for heavy duty applications.This flat-free universal replacement wheelbarrow wheel has a rib tread and a 75mm Tread Width. It has a special foam filled tyre that has the same cushioning and bounce as a typical pneumatic wheel. As the name suggests, it has the added benefit of not being susceptible to punctures from nails and other sharp objects.Changing the bore size:
The hub of this wheel arrives to you fitted with a 16mm (5/8" bearing). This can be removed and replaced with 19mm (3/4" bushes) wheel bushes if needed. The 19mm bushings are included in the kit.To change the bore size simply remove the existing bearings by gently prising both out with a screwdriver and hammer. To prevent damaging the new bushings when knocking them in gently with a hammer, it is recommended that a piece of wood is placed over the bearing:The wheel has a 75mm hub (the distance through the central bore). This can be extended to suit your wheelbarrow by the use of the spacers supplied (see image below for details):When replacing your wheelbarrow's front wheel, it is advised that you remove the wheel from the wheelbarrow and check the shaft size and the hub length (the distance through the central bore) before purchasing. If you have any doubts, please do not hesitate to phone or send us an email for assistance. - In Stock
Pallet Roller, 85mm X 80mm, Polyurethane Tyre, 20mm Ball Bearing, 700kg (KR8580PTB)
Original price was: £29.78.£22.36Current price is: £22.36.Sale!85mm X 80mm Pallet Roller with a polyurethane tyre... Read More (92 Shore A Hardness) on a steel centre. 20mm Ball Bearing and a Load Capacity of 700kg (working speed 4 km/h).This pallet roller is abrasion resistant with a low rolling resistance.
