In Stock175mm Swivel Castor (Powder Coated), 800kg Capacity | Polyurethane Tyre Wheel (KGHP175ASFMUD)
Original price was: £152.55.£88.44Current price is: £88.44.Sale!175mm Heavy-duty Swivel Castor with a Powder Coate... Read Mored Pressed Steel Bracket and a 225mm overall height. The caster wheel has a Blue Polyurethane Tyre (Shore A 95) on an Aluminium Centre with Ball BearingsFeatures:- 800kg Load Capacity: For the most demanding applications and heavy-duty loads.
- Silver/Grey Powder Coating: Making this the best looking heavy-duty industrial castor on the market. The powder-coating not only looks great but also provides corrosion protection which prolongs its optimal performance and keeps the castor looking good.
- Quality Ball Bearings: For the lowest rolling resistance to reduce the effort needed to move.
- Double Ball Bearing Race and hardened bearing Seats in the swivel head: For an optimum swivel rotation function and durability.
- Strong Pressed Steel Plate: The top plate measure 140x110mm with fixing bolt holes slotted to 105x80/75mm to suit 10mm bolts
- Precision Engineered: These castors have an incredibly smooth swivelling function with no "rock" to the swivel head and no sideways movement on the wheel for exceptional operating performance.
- Discontinued
Castor Wheel 100mm | Polyurethane Tyre / Nylon Centre, 250kg, 15mm Plain Bore (WPN4M15)
£11.96100mm Red Polyurethane Tyre on a Grey Nylon Centre... Read More castor wheel with 35mm Tread Width, 48mm Hub Length and 15mm smooth plain bore. Load Capacity = 250kgThis product has been discontinued. Our alternative is the KW100PN1548 (click here to view castor wheel)KW100PN1548 Specifications:- Diameter: 100mm
- Central Bore: 15mm
- Tread Width: 34mm
- Hub Length: 48mm
- Load Capacity: 220kg
- In Stock
125mm Swivel Castor, 200kg Capacity | Rubber Tyre Wheel, Ball Bearing (MSV125RN2B)
£12.45125mm Blue Elastic Rubber Tyre on a nylon centr... Read Moree wheel with a ball bearing fitted into a pressed steel swivel castor bracket. The Swivel Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 200kg using manual propulsion at 4km/h (walking speed)
The Blue Elastic Rubber Tyre offers a higher load capacity than standard grey or black rubber tyres and is non-marking, gentle on floors and the rubber absorbs vibrations whilst in motion making this a low noise option. The ball bearing lowers the rolling resistance to reduce the effort required to move the castors. Together with the strong bracket that has a double ball race in the swivel head makes this castors a great performer and one of our most popular products.</p>
- Out of Stock - On the Way
200mm Swivel Castor with Brake, 2500kg Capacity | Nylon Wheel, Ball bearing (GXT200BSFMCD)
Original price was: £585.96.£368.00Current price is: £368.00.Sale!200mm Machine Ca... Read Morest Nylon Wheel fitted into an extra strong Fabricated Top Plate Swivel Castor with wheel brake and 148/132x111/99mm bolt hole centres. The slotted bolt holes cover the European and UK standard 140x105mm bolt holes. The load capacity of this castor is 2500kg at 4km/hThis high performance castor is fitted with a white machine cast nylon wheel that will not mark the floor. An extra strong welded castor frame that is powder coated and fitted with a high performance castor wheel containing two ball bearings that turns on a specially designed integrated axle shaft arrangement makes this castor one of the most durable in the market. Perfect for moving very heavy loads where strength, durability and performance are criticalThe swivel head of the 125mm - 250mm sizes of the GXT range come with a thrust bearing and a taper roller bearing in the swivel head. - In Stock
Castor Wheel 150mm | Blue Rubber Tyre / Nylon Centre, 300kg, 20mm Roller Bearing (KWRN6RBM20)
£17.42150mm Blue Elastic Rubber Tyre on a Black Nylon Ce... Read Morentre with a 48mm Tread Width, 60mm Hub Length (distance through the central hole) and a 20mm Roller Bearing. Load Capacity = 300kg - In Stock
Castor Wheel 200mm | Rubber Tyre / Cast Iron, 535kg, 20mm Roller Bearing (200RU15)
£50.39200mm Rubber Tyre / Cast Iron Center wheel with 20... Read Moremm Roller Bearing. Load Capacity 553kg - In Stock
125mm Swivel Castor, 100kg Capacity | Rubber Tyre Wheel, Roller Bearing (LSV125RMB)
£8.81125mm Top Plate Swivel Castor with a Black Rubber ... Read MoreTyre Wheel on a Pressed Steel centre complete with Thread Guards. It has 80x60mm bolt hole centres and a load capacity of 100kg using manual propulsion at 4km/h.This popular general purpose castor is fitted with a Black Rubber Tyre Wheel that is gentle on floors. The Caster wheel has a roller bearing that offers low rolling resistance. It is ideal as a new or replacement castor for most domestic or industrial applications such as a trolley or dolly where the travel speed of the castor generally does not exceed walking speed. - In Stock
125mm Fixed Castor, 300kg Capacity | Nylon Wheel, Ball bearing (HKF12520111)
£36.77125mm Top Plate Fixed Castor (Fabricated Steel) wi... Read Moreth 105x80 Hole Centres. Nylon Wheel with Ball bearing. Load Capacity = 300kg - In Stock
Castor Wheel 100mm | Polyurethane Tyre / Nylon Centre, 200kg, 12mm Roller Bearing (KW100PNB1240)
£9.61100mm Red Polyurethane Tyre Castor Wheel with a Wh... Read Moreite Nylon Centre and 12mm Needle Roller Bearing, 35m Tread Width and 40mm Hub Length (the distance through the central bore / hole). The Load Capacity of with wheel is 200kg. - In Stock
100mm Fixed Castor | Polyurethane Tyre Wheel, Roller Bearing, 180kg Capacity (MFZ100PN1B)
Original price was: £10.43.£7.04Current price is: £7.04.Sale!100mm Red Polyurethane Tyre Wheel on a Nylon Centr... Read Moree with a roller bearing fitted into a pressed steel Fixed castor bracket. The Fixed Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 180kg using manual propulsion at 4km/h (walking speed)The Polyurethane tyre offers a low tractive resistance making it easier to get moving compared with softer rubber tread wheels. It is also a bit softer than hard tread wheels making the castor smoother and quieter running. The polyurethane tyre is also non-marking and gentle on floors while the roller bearing lowers the rolling resistance to reduce the effort required to move the castors. Put this wheel into a strong bracket and you have a castor that is a great choice for the wide range of industrial and domestic applications. - In Stock
100mm AGV Swivel Castor, Twin Wheel, 310kg Load | Polyurethane Wheel, Ball bearing (GATD100ASFHUD)
Original price was: £569.41.£220.07Current price is: £220.07.Sale!This Twin wheel ... Read More100mm Automated Guided Vehicle (AGV) Castor has a bracket made from strong Forged steel that is zinc plated. There is a hardened Taper Roller Bearing in he swivel head, which has a grease nipple, for smooth swivelling action and durability. The Top Plate is 112mm x 112mm and has 4 bolt holes that are spaced 92mm x 92mm, each with a 9mm hole diameter.The castor is able to tilt +/- 5o from its central axis according to the flatness of the floor. This ensures that this castor's wheels keep contact with the floor allowing smooth AGV movement and protection of the loaded cargo when changing directions (See illustration below)The wheels are more widely separated from each other than most Twin Wheel Castors. When changing direction, the two wheels spin in opposite directions to each other which reduces the castor offset. The smaller the offset the less chance that the AGV will deviate from its designated line.This castor frame has two wheels with a Polyurethane tyre (Shore A 95) on an Aluminium centre each containing ball bearings, The polyurethane wheel has excellent elasticity the minimises slipping that can happen when an AGV starts or stops. In addition, the elasticity also absorbs small shocks arising from small imperfections in the floor. The wheel itself is non marking and will not damage the floor. - In Stock
Designer Polyurethane Tyre Wheel 100mm | Polyurethane Tyre / Cast Iron, 500kg, 20mm Ball Bearing (10040PT220)
£105.70100mm Polyurethane (Extra Heavy Duty) Tyred / C... Read Moreast Iron Centre Wheel with 20mm Ball Bearing. This is a high performance wheel using premium grade REVVOTHANE polyurethane which is a high quality tyre with a high load bearing capacity, minimal heat build up and a high abrasion resistance. This wheel is often used in conveyor and transportation systems.
The Load capacity quoted is for operation under ideal conditions where the wheel operates infrequently and on a smooth surface. The wheel's load capacity must be reduced as indicated for any of the following conditions. Please note that these are cumulative if more than one condition exists:
- Reduce load by 25% if continuous use for more than 45 minutes.
- Reduce Load by further 30% if used as Drive Wheel.
- Reduce load by further 30% if used at speeds greater than 6kp/h.
- In Stock
Castor Wheel 125mm | Nylon, 350kg, 15mm Roller Bearing (KW125NY1547RB)
£8.44125mm Nylon Wheel with 47mm Hub Length (Distance t... Read Morehrough the central bore) and a 15mm Roller Bearing. Load Capacity = 350kg - In Stock
125mm Swivel and Brake Castor, 100kg Capacity | Polypropylene Wheel, Plain Bore (LSV125PPBHBR)
£9.62125mm White Polypropylene wheel fitted in a 12m... Read Morem Single Bolt Hole Swivel and Brake Castor (Pressed Steel castor frame). This castor has a 100kg load capacity using manual propulsion at 4 km/h.
This castor is fitted with a White Polypropylene wheel that will not mark the floor and is ideal for most general castor purposes such as trolley castors or dolly castors. Single Bolt Hole castors can have a expander tube fitting (purchased separately) attached to insert into hollow square or round tubing. See our section on Expander Tube Fittings
- Out of Stock - On the Way
125mm Fixed Castor, 180kg Capacity | Rubber Tyre Wheel, Plain Bore (588RN)
£27.13125mm Top Plate Fixed Castor (Pressed Steel) with ... Read More121x80 Hole Centres. Rubber Tyre / Nylon Centre Wheel with Plain Bore. Load Capacity = 180kg
