Swivel Castors
Swivel Castors and wheels can swivel 360 degrees about the vertical axis (see figure below). They consist of a housing and a caster wheel. The housing itself is made up of a plate fitting, swivel bearings and a yoke. The Yoke is often referred to as the castor's frame (see figure below).The plate fitting determines how the... castor is going to be attached to the equipment. It is usually either a single bolt hole fitting or a plate fixing which is generally square, rectangular or triangular. Plate fittings are usually bolted to equipment so knowing your required bolt hole centres is important. The Swivel Head consists of a ball race and a number of ball bearings that roll within it. Swivel Castors can either have a single ball race or a double ball race. They perform the same function. The double ball race was developed for medium and heavy applications. This is because they are compact, perform well under static and dynamic loads and provide excellent steerability.
Swivel castors can be fitting with locks which lock (brake) wither the wheel or the swivel head or both. See Brake Castors.
Swivel Castor Components
Swivel Castor Offset
The Swivel Castor's offset it the distance from the swivel axis to the centre of the wheel (where it is secured to the castor frame). It is the reason a swivel castor will go in the direction you want it to go regardless its starting direction. The offset and castor wheel's diameter make up the swivel radius where the swivel radius = Offset + (Wheel Diameter / 2).
This is the radius of circle described but the outer dimension of the wheel swivelling around the vertical axis. Basically, this is important because it tells you how much room is needed for the swivel caster to swivel. Furthermore, the general rule is the bigger the offset the better the castor's running performance but the lower the weight it can carry. Read More
- Display 15 Products per page
In Stock75mm Pressed Steel Swivel Castor, 170kg Capacity | Nylon Wheel, Plain Bore (K075VNY)
Original price was: £9.46.£7.68Current price is: £7.68.Sale!75mm Swivel Castor with Triangular Mounting Plate ... Read Moreand 102x73mm Hole Centres housing a white nylon wheel with a smooth plain bore. This castor has an overall height of 95mm and a load capacity of 170kg.The top plate has two extra long slotted bolt holes to allow for easy positioning along a profile. It is often fitted to frame such as a T-Slot Aluminium Extrusion Profile to provide extra clearance.- In Stock
150mm AGV Swivel Castor, Twin Wheel, 630kg Capacity | Polyurethane Wheel, Ball bearing (GASD150ASFHUD)
Original price was: £828.35.£320.14Current price is: £320.14.Sale!This Twin wheel ... Read MoreAutomated Guided Vehicle (AGV) Castor with 150m diameter wheels has shock absorbing function and a bracket made from strong Forged steel that is zinc plated. There is double thrust bearing in the swivel head to achieve a high load capacity and maintain castor performance and durability.The role of the spring in an AGV castor is different to that of a standard shock absorbing castor. In a standard shock absorbing castor, the spring absorbs shock and noise whereas, it's role in a AGV castor is primarily to keep the wheels in contact with the floor.When determining the overall height requirement of a shock absorbing AVG, it should be designed based on the spring cushion being fully compressed.The shock absorbing pad made from a special rubber compound absorbs minor shocks and vibrations to protect the AGV unit. There is a 10mm range of compression which helps prevent the castors from losing contact with the floor which may be caused by small floor imperfections. An AGV's castor leaving the floor when changing directions is often the cause of the AGV becoming unbalanced and coming to a stop by straying off its designated path.The Top Plate is 145mm x 145mm and has 4 bolt holes that are spaced 120mm x 120mm, each with a 11mm hole diameterThis castor frame has two wheels with a Polyurethane tyre (Shore A 95) on an Aluminium centre each containing ball bearings, Having a twin wheel castor is great for reducing the effort required to swivel the castor and most efficient by reducing the amount of room the castor needs to turn the AGV Cart.The polyurethane wheel has excellent elasticity the minimises slipping that can happen when an AGV starts or stops. In addition, the elasticity also absorbs small shocks arising from small imperfections in the floor. The wheel itself is non marking and will not damage the floor. - In Stock
100mm Swivel Castor with 24mm to 27mm Round Expander Fitting, 100kg Capacity | Rubber Tyre Wheel (194557)
Original price was: £13.49.£8.10Current price is: £8.10.Sale!100mm Grey Therm... Read Moreoplastic Rubber Tyre Wheel on a nylon centre fitted into a 10mm Single Bolt Hole Swivel Castor (Pressed Steel Frame) complete with a 24mm - 27mm Round Expander. The swivel head has a double ball race and the load capacity of this castor is 100kg using manual propulsion at 4km/h.The expander fitting is designed to fit into an round hollow tube with an internal diameter of 24mm to 27mm.This castor is fitted with a grey rubber tyre that will not mark or damage the floor and is ideal for most general, light duty castor purposes such as trolley castors or dolly castors. The Ball Bearing in the wheel provides excellent rolling performance. - In Stock
75mm AGV Swivel Castor, 100kg Capacity | Polyurethane Wheel, Ball bearing (GAPL75ASFHUD)
Original price was: £66.49.£25.70Current price is: £25.70.Sale!75mm Automate... Read Mored Guided Vehicle (AGV) Castor has a bracket made from strong pressed steel with precision ball bearings in the swivel head for smooth swivelling action and durability. The load capacity of this castor is 100kg
The bolt holes are slotted to 78mm x 45mm / 72mm x 45mm with a 9mm hole diameter,
This castors is fitted a Polyurethane tyre (Shore A 90) on an Aluminium centre containing ball bearings, The polyurethane wheel has excellent elasticity the minimises slipping that can happen when an AGV starts or stops. In addition, the elasticity also absorbs small shocks arising from small imperfections in the floor. The wheel itself is non marking and will not damage the floor.
Many AGV applications require the castor to run 24 hours a day and the durability of the castor is important to reduce costs associated with stoppage. By using bearing steel with a higher strength than general steel in the swivel head, this castor has an exceptional performance.
- In Stock
50mm Compact Swivel Castor, 150kg Capacity | 50mm Polyurethane Tyre Wheel, Ball bearing (KS050PT2B)
£15.6550mm Low Level swivel castor with 90x66mm Top Plat... Read Moree and 75/61x51/45mm Fixing Bolt Hole Centres. This Low Level compact castor has an overall height of 73mm and an Orange Polyurethane Wheel on a steel centre with a 33mm Tread Width and Ball bearings. Load Capacity = 150kg - In Stock
75mm Footmaster Levelling Castor, Plate Fitting, 800kg Capacity | Nylon Wheel (KGD-100F)
£62.7575mm Foot Master Levelling Castor with an Ivory... Read More Colour powder coating finish. This product has a 4-hole top plate with 70mm x 70mm bolt hole centres which is also powder coated for added protection. The wheel is made from premium quality black Nylon with a 30mm Tread width and the Die Cast Aluminium Foot Pad has a rubber vibration damping pad. This foot pad has a Nylon Hand-wheel operation
This product's load capacity has increased to 800kg Static Load and 400kg Dynamic Load.
Because of the lifting and lowering function of the Foot Master castor, like all Jacking Castors, it is important understand that each castor may be subjected to HALF THE TOTAL WEIGHT. Therefore, the recommended load capacity for each Foot Master Levelling Castor is half the castor's Static Load Capacity, that is, when the castors' levelling function is not being used. The load capacity of the Footmaster Castor when it is being moved and positioned is given by the Dynamic Load Capacity.
This levelling castor is a multi-functional swivel castor that provides mobility, levelling and anti-vibration functions. This allows users to move and position large equipment into place with added stability using the levelling and anti-vibration features.
- In Stock
50mm Stainless Steel Footmaster Levelling Castor, 280kg Capacity | Nylon Wheel, Plain Bore (KSGDN-60F)
Original price was: £148.64.£104.05Current price is: £104.05.Sale!50mm Stainless Steel Footmaster levelling castor h... Read Moreas a stainless steel forged steel plate and castor frame. This castor has a Top Plate Fitting and 280kg Static and 140kg Dynamic Load Capacity. Machine Cast Nylon Wheel With Vibration Damping Rubber Pad. Nylon Handwheel height adjustment operation. The overall height is 82mm when the wheel is engaged with a total lift of up to 15mm using the rubber footpad.This stainless steel Footmaster Levelling castor has a double ball bearing with hardened stainless steel bearings in the swivel head and has completely corrosion-resistant components applied.Footmaster levelling castors are a multi-functional swivel castor that provides mobility, levelling and anti-vibration functions. This allows users to move and position large equipment into place.Because of the lifting and lowering function, like regular Jacking Castors, it is important understand that each castor may be subjected to HALF THE TOTAL WEIGHT. Therefore, the recommended load for each Footmaster Castor is half the castor's Static Load Capacity of when the castor is stationary and the foot-pads are lowered.This load capacity of the Footmaster Castor when being moved and positioned is given by the Dynamic Load Capacity. - In Stock
125mm Swivel Castor, 325kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (561SUB)
£53.61125mm Top Plate Swivel Castor made from Pressed St... Read Moreeel (Flexello Brand) and has a ball bearing swivel race. The Top Plate has four fixing holes to suit 10mm bolts and are slotted to 140/120mm x 105/95mm Bolt Hole Centres. The caster wheel has a Red Polyurethane Tyre on a Cast Iron Centre Wheel with with A 35mm Tread Width and a Needle Roller Bearing. Load Capacity = 325kg - In Stock
100mm Heavy Duty Swivel Castor, 500kg Capacity | White Nylon Wheel, Ball Bearing (HSV100NY2B)
£27.06This 100mm heavy-duty swivel castor is designed fo... Read Morer demanding applications in both industrial and domestic settings. Featuring a top plate made from heavy gauge pressed steel, it offers exceptional durability and strength. The swivel head includes a double ball race with a hardened ball race track, ensuring smooth and reliable movement.Key Features:- Load Capacity: Supports up to 500kg, making it ideal for heavy loads.
- Top Plate Dimensions: Measures 105x80mm, with fixing bolt hole centres at 80x60mm. The slotted bolt holes (80/75×60/55mm) accommodate 8mm bolts for easy installation.
- Wheel Material: The castor features a white nylon (polyamide) wheel with a 37mm tread width, designed to provide non-marking performance.
- Precision Bearings: Fitted with two precision ball bearings, this castor offers the lowest rolling and swivel resistance in its class, ensuring effortless movement even under heavy loads.
- In Stock
60mm Compact Twin Wheel Swivel Castor, 200kg Capacity | Polyurethane Tyre Wheel, Ball bearing (2KS060PT2B)
£23.4860mm Low Level twin wheel swivel castor with 105x8... Read More0mm Top Plate and 80/76x60mm Fixing Bolt Hole Centres. This Low Level compact castor has an overall height of 80mm and an Orange Polyurethane Wheel on a steel centre with a 2x19mmTread Width (41mm across both wheels) and Ball bearings. Load Capacity = 150kg.The swivel head has a double ball race for excellent swivelling and the polyurethane tyres have a 95 Shore A hardness. - In Stock
63mm Black Footmaster Levelling Castor, Plate Fitting, 550kg Capacity | 63mm Nylon Wheel (KGD-80FBLACK)
£51.3663mm Foot Master Levelling Castor with an Black po... Read Morewder coating finish. This product has a 4-hole top plate with 70mm x 70mm bolt hole centres and is also powder coated for added protection. The wheel is made from premium quality black Nylon with a 28mm Tread width and the Die Cast Aluminium Foot Pad has a rubber vibration damping pad. This foot pad has a Nylon Hand-wheel operationThis product's load capacity has increased to 550kg Static Load and 275kg Dynamic Load.Because of the lifting and lowering function of the Foot Master castor, like all Jacking Castors, it is important understand that each castor may be subjected to HALF THE TOTAL WEIGHT. Therefore, the recommended load capacity for each Foot Master Levelling Castor is half the castor's Static Load Capacity, that is, when the castors' levelling function is not being used. The load capacity of the Footmaster Castor when it is being moved and positioned is given by the Dynamic Load Capacity.This levelling castor is a multi-functional swivel castor that provides mobility, levelling and anti-vibration functions. This allows users to move and position large equipment into place with added stability using the levelling and anti-vibration features. - In Stock
50mm Swivel Castor, 27kg Capacity | Rubber Tyre Wheel, Plain Bore (961RN)
£5.2850mm Top Plate Swivel Castor (Pressed Steel) with ... Read More54x25mm Fixing Bolt Hole Centres and 64mm Overall Height. The wheel is a Blue Rubber Tyre on a Black Nylon Centre Wheel with a Smooth Plain Bore and a 22mm Tread Width. Load Capacity = 27kg.The blue rubber tyre wheel has a soft tread and is both gentle on floors and non-marking. It also absorbs fine vibrations whilst moving which provides user comfort and limits noise. - In Stock
125mm Swivel Castor, 300kg Capacity | Polyurethane Tyre Wheel, Ball Bearing (MSK125PA2B)
£40.47125mm Top Plate Swivel Castor (Pressed Steel) with... Read More 80x60mm Fixing Bolt Hole Centres. Polyurethane Tyre on an Aluminium Centre Wheel with Ball Bearings. Load Capacity = 300kg.This castor is made from heavy gauge pressed steel with a 5mm thick Top Plate and 4mm Castor Forks. It is a product that is built to last and is great for arduous applications. - In Stock
50mm Swivel Castor, 50kg Capacity | Rubber Tyre Wheel, Plain Bore (LSV050RP)
£2.3250mm Swivel Castor with a non-marking Grey Rubber ... Read MoreTyre Wheel on a nylon centre. This castor is made from Pressed Steel and has a Top Plate with 36x36mm bolt hole centres which suit a 6mm fixing bolt. The load capacity of this castor is 50kg using manual propulsion at 4km/hThis popular general purpose castor is fitted with a grey rubber tyre wheel that will not mark or damage the floor. It is ideal for most domestic and industrial castor uses where a small yet sturdy castor in needed. For example, on a trolley or dolly. - In Stock
160mm Swivel Castor, 200kg Capacity | Rubber Tyre Wheel, Roller Bearing (MSVH160RN1B)
£23.23160mm Single Bolt Hole (12mm) Swivel Castor (Press... Read Moreed Steel). Blue Rubber Tyred / Nylon Centre Wheel with Roller Bearing. Load Capacity = 200kg
