Description
200mm Shock absorbing (15mm Compression) fixed castor with Brake and Polyurethane Tyre on an Aluminium Centre Wheel. Load Capacity = 450kg
For the compression performance, please see the image for the curve by clicking on the thumbnail image above. To use this curve, calculate the weight being carried by this castor and divide that by the one less than the number of castors on your equipment.
For a typical example, with a trolley or machinery using 4 of these castors please divide the total weight by 3. If the total weight being carried is 500kg then the relevant reading for the compression of the rubber pad on the chart’s ‘Y’ axis is given at 167kg (500kg / 3 = 167kg) along the ‘X’ axis, which is just over 10mm.
