Pressed Steel Castors
Pressed steel castors are used in a wide variety of applications such as trolleys, shop-fitting equipment, displays, institutional and apparatus equipment as medical applications. They are available as Swivel Only, Swivel & Brake or Fixed (sometime called Rigid) castors.The forks of the castor, which are the two side p...lates that hold the wheel, are formed by machine pressing a single piece of steel.
They can be secured to your equipment by either a multiple hole (usually 4 Hole) Top Plate fastening or a single Bolt Hole Fitting which can be fitted with an expander fitting to suit a hollow tube.
The swivelling characteristics of pressed steel castors are affected by the castor's offset and wheel diameter. Furthermore, the construction of the swivel bearing also plays a part.
- A single ball race swivel castor is suitable for apparatus and transportation (e.g. trolleys) and enable good steering with a compact design.
- A double ball race swivel castor is available for medium and heavy duty requirements and it provides excellent performance under heavier loads as compared with a single ball race.
In Stock100mm Black Fixed Castor, 200kg Capacity | Rubber Tyre Wheel, Ball Bearing (MFV100BRN2B)
£10.43 Compare100mm All Black Fixed Castor with Black Elastic Ru... Read Morebber Tyre on a nylon centre wheel with a single ball bearing. This castor is designed for theatre applications to reduce reflection from lighting. It can also be used in any application where a pressed steel castor is required.The Swivel Brake Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 200kg using manual propulsion at 4km/h (walking speed)The Black Elastic Rubber Tyre offers a higher load capacity than standard grey or black rubber tyres and is quiet and gentle on floors. The soft tread rubber (65 Shore A) absorbs vibrations whilst in motion making this a low noise option. The ball bearing lowers the rolling resistance to reduce the effort required to move the castors. Together with the strong bracket that has a double ball race in the swivel head makes this castors a great performer and one of our most popular products.DOWNLOAD CATALOGUE PAGE HEREQty- In Stock
100mm Black Swivel Castor with Brake, 200kg Capacity | Rubber Tyre Wheel, Ball Bearing (MSV100BRN2BSWB)
£15.29 Compare100mm All Black Swivel & Brake Castor with Bla... Read Moreck Elastic Rubber Tyre on a nylon centre wheel with a single ball bearing. This castor is designed for theatre applications to reduce reflection from lighting. It can also be used in any application where a pressed steel castor is required.The Swivel Brake Bracket has a 4 hole top plate with 80/77x60mm bolt hole spacing. The load capacity of this castor is 200kg using manual propulsion at 4km/h (walking speed)The Black Elastic Rubber Tyre offers a higher load capacity than standard grey or black rubber tyres and is quiet and gentle on floors. The soft tread rubber (65 Shore A) absorbs vibrations whilst in motion making this a low noise option. The ball bearing lowers the rolling resistance to reduce the effort required to move the castors. Together with the strong bracket that has a double ball race in the swivel head makes this castors a great performer and one of our most popular products.DOWNLOAD CATALOGUE PAGE HEREQty - In Stock
100mm Black Swivel Castor, 200kg Capacity | Rubber Tyre Wheel, Ball Bearing (MSV100BRN2B)
£13.16 Compare100mm All Black Swivel Castor with Black Elastic R... Read Moreubber Tyre on a nylon centre wheel with a single ball bearing. This castor is designed for theatre applications to reduce reflection from lighting. It can also be used in any application where a pressed steel castor is required.The Swivel Brake Bracket has a 4 hole top plate with 80/77x60mm bolt hole spacing. The load capacity of this castor is 200kg using manual propulsion at 4km/h (walking speed)The Black Elastic Rubber Tyre offers a higher load capacity than standard grey or black rubber tyres and is quiet and gentle on floors. The soft tread rubber (65 Shore A) absorbs vibrations whilst in motion making this a low noise option. The ball bearing lowers the rolling resistance to reduce the effort required to move the castors. Together with the strong bracket that has a double ball race in the swivel head makes this castors a great performer and one of our most popular products.DOWNLOAD CATALOGUE PAGE HEREQty - In Stock
100mm Fixed Castor | Polyurethane Tyre Wheel, Roller Bearing, 180kg Capacity (MFZ100PN1B)
100mm Red Polyurethane Tyre Wheel on a Nylon Centr... Read Moree with a roller bearing fitted into a pressed steel Fixed castor bracket. The Fixed Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 180kg using manual propulsion at 4km/h (walking speed)The Polyurethane tyre offers a low tractive resistance making it easier to get moving compared with softer rubber tread wheels. It is also a bit softer than hard tread wheels making the castor smoother and quieter running. The polyurethane tyre is also non-marking and gentle on floors while the roller bearing lowers the rolling resistance to reduce the effort required to move the castors. Put this wheel into a strong bracket and you have a castor that is a great choice for the wide range of industrial and domestic applications.£9.72Original price was: £9.72.£6.80Current price is: £6.80.Sale! CompareQty - In Stock
100mm Fixed Castor, 125kg Capacity | Polypropylene Wheel, Plain Bore (LFV100PP)
£4.59 Compare100mm Top plate Fixed Castor with a White Polyprop... Read Moreylene Wheel. It has 80x60mm bolt hole centres and a load capacity of 125kg using manual propulsion at 4km/h.This is one of our most popular castors and the White Polypropylene wheel is non-marking and won't damage concrete floors. Because it is a hard tread it has the lowest rolling and swivelling resistance. It is ideal as a new component or a replacement caster for most general purpose domestic or industrial castor where the travel speed of the castor generally does not exceed walking speed.Qty - In Stock
100mm Fixed Castor, 150kg Capacity | Nylon Wheel, Ball Bearing (1321958)
£7.68 Compare100mm Top Plate Fixed Castor (Pressed Steel) wi... Read Moreth 80x60 Hole Centres. Nylon Wheel with Ball Bearing. Load Capacity = 150kg
This is a 4 hole plate fitting castor and the bolt holes suit an 8mm bolt as well as being slotted (rather than round) to accommodate 80/76mm x 60x44.5mm.
Qty - In Stock
100mm Fixed Castor, 150kg Capacity | Nylon Wheel, Ball Bearing (MFV100NY2B)
£6.48 Compare100mm White Nylon Wheel with a ball bearing fitted... Read More into a pressed steel Fixed castor bracket. The Fixed Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 150kg using manual propulsion at 4km/h (walking speed)The Nylon Wheel has a low tractive resistance making it easier to get moving compared with softer rubber tread wheels. Together with the strength of nylon and because it wont damage concrete floors, makes nylon wheel castors probably the most popular choice. The ball bearing lowers the rolling resistance to reduce the effort required to move the castors. Put this wheel into a strong bracket makes this castor a great choice for the widest range of industrial and domestic applications.Qty - In Stock
100mm Fixed Castor, 150kg Capacity | Nylon Wheel, Plain Bore (1321950)
£5.77 Compare100mm Top Plate Fixed Castor (Pressed Steel) wi... Read Moreth 80x60 Hole Centres. Nylon Wheel with Plain Bore. Load Capacity = 150kg
This is a 4 hole plate fitting castor and the bolt holes suit an 8mm bolt as well as being slotted (rather than round) to accommodate 80/76mm x 60x44.5mm.
Qty - In Stock
100mm Fixed Castor, 150kg Capacity | Nylon Wheel, Roller Bearing, 8mm Bolt Hole (MFV100NY1B)
£6.36 Compare100mm White Nylon Wheel with a roller bearing f... Read Moreitted into a pressed steel Fixed castor bracket. The Fixed Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 150kg using manual propulsion at 4km/h (walking speed)
The Nylon Wheel has a low tractive resistance making it easier to get moving compared with softer rubber tread wheels. Together with the strength of nylon and because it wont damage concrete floors, makes nylon wheel castors probably the most popular choice. The roller bearing lowers the rolling resistance to reduce the effort required to move the castors. Put this wheel into a strong bracket makes this castor a great choice for the widest range of industrial and domestic applications.
Qty - In Stock
100mm Fixed Castor, 150kg Capacity | Polyurethane Tyre Wheel, Ball Bearing (MFV100PN2B)
£9.36 Compare100mm Red Polyurethane Tyre Wheel on a Nylon Ce... Read Morentre with a ball bearing fitted into a pressed steel Fixed castor bracket. The Fixed Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 150kg using manual propulsion at 4km/h (walking speed)
The Polyurethane tyre offers a low tractive resistance making it easier to get moving compared with softer rubber tread wheels. It is also a bit softer than hard tread wheels making the castor smoother and quieter running. The polyurethane tyre is also non-marking and gentle on floors while the ball bearing lowers the rolling resistance to reduce the effort required to move the castors. Put this wheel into a strong bracket and you have a castor that is a great choice for the wide range of industrial and domestic applications.</p>
Qty - In Stock
100mm Fixed Castor, 150kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (1321986)
£10.39 Compare100mm Top Plate Fixed Castor (Pressed Steel) with ... Read More80x60 Hole Centres. Polyurethane Tyre / Nylon Centre Wheel with Roller Bearing. Load Capacity = 150kgThis is a 4 hole plate fitting castor and the bolt holes suit an 8mm bolt as well as being slotted (rather than round) to accommodate 80/76mm x 60x44.5mm.Qty - In Stock
100mm Fixed Castor, 150kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (MFK100PN1B)
£10.57 Compare100mm Top Plate Fixed Castor (Pressed Steel) with ... Read More80x60 Hole Centres. Polyurethane Tyre / Nylon Centre Wheel with Roller Bearing. Load Capacity = 150kgQty - In Stock
100mm Fixed Castor, 150kg Capacity | Polyurethane Tyre Wheel, Roller Bearing (MFV100PN1B)
£6.88 Compare100mm Red Polyurethane Tyre Wheel on a Nylon Centr... Read Moree with a roller bearing fitted into a pressed steel Fixed castor bracket. The Fixed Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 150kg using manual propulsion at 4km/h (walking speed)The Polyurethane tyre offers a low tractive resistance making it easier to get moving compared with softer rubber tread wheels. It is also a bit softer than hard tread wheels making the castor smoother and quieter running. The polyurethane tyre is also non-marking and gentle on floors while the roller bearing lowers the rolling resistance to reduce the effort required to move the castors. Put this wheel into a strong bracket and you have a castor that is a great choice for the wide range of industrial and domestic applications.Qty - In Stock
100mm Fixed Castor, 150kg Capacity | Rubber Tyre Wheel, Ball Bearing (1321968)
£10.11 Compare100mm Top Plate Fixed Castor (Pressed Steel) wi... Read Moreth 80x60 Hole Centres. Blue Rubber Tyre / Nylon Centre Wheel with Ball Bearing. Load Capacity = 150kg
This is a 4 hole plate fitting castor and the bolt holes suit an 8mm bolt as well as being slotted (rather than round) to accommodate 80/76mm x 60x44.5mm.
Qty - In Stock
100mm Fixed Castor, 160kg Capacity | Rubber Tyre Wheel, Ball Bearing (MFV100RN2B)
£8.59 Compare100mm Blue Elastic Rubber Tyre on a nylon centr... Read Moree wheel with a ball bearing fitted into a pressed steel Fixed castor bracket. The Fixed Bracket has a 4 hole top plate with 80x60mm bolt hole spacing. The load capacity of this castor is 160kg using manual propulsion at 4km/h (walking speed)
The Blue Elastic Rubber Tyre offers a higher load capacity than standard grey or black rubber tyres. It is also non-marking, gentle on floors and the rubber absorbs vibrations whilst in motion making this a low noise option. The ball bearing lowers the rolling resistance to reduce the effort required to move the castors. Together with the strong bracket makes this castors a great performer and one of our most popular products.</p>
This castor is often used on flight cases as well as in many medical, industrial and domestic applications.<br></p>
Qty
