Description
65mm Shock absorbing Fixed Castor with Wheel Brake and a Top plate measuring 55x55mm with 42x42mm fixing bolt holes centres to suit 6mm fixing bolts. The wheel as a soft (Shore 80A) polyurethane tyre for high elasticity and is fitted with a precision ball bearing. This castor has as load capacity of 50kg.
The brake locks only the wheel and allows the swivel head to rotate freely when the brake is applied. The Top Plate is made from pressed steel and the frame is aluminium. The parts have powder coated and zinc plated for protection
The shock absorbing functions means that the overall height can vary by 10mm. The castor’s height without load is 115mm and this reduces incrementally by up to 10mm as the load increases providing up t0 10mm of compression for a fine shock absorbing function.
